QSC AD-C1200BB ตู้ลำโพงสำหรับดอกลำโพง AD-C1200

 โพสต์เมื่อ : 25 พ.ย 2567 เวลา 0:50 น.
17

17

รหัส : AD-C1200BB
ยี่ห้อ : QSC
รุ่น : QSC AD-C1200BB
ราคาปกติ :  36,000.00 บาท
ราคาพิเศษ :  34,200.00บาท
รายละเอียดย่อ :
High performance enclosure of AD-C1200 loudspeaker system.

ราคาพิเศษ สอบถามโทร 080-6144774 , 02-9810944

รายละเอียดทั้งหมด

Features

  • 12-inch low-frequency woofer
  • 1.75-inch diaphragm compression driver
  • 300-watt continuous power rating
  • 70V/100V multi-tap transformer included (system can operate in distributed or low-impedance mode)

Package Includes:
One AD-C1200 loudspeaker baffle assembly
(Backbox enclosure (AD-C1200BB) and grille (AD-C1200SG) sold separately)




SPECIFICATIONS
 		AD-C1200
ConfigurationPassive
Low-frequency Transducer12-inch (304 mm) ferrite woofer
Hight-frequency Transducer1.75-inch (44 mm) neodymium compression driver
Frequency Range 1
Frequency Response (-6 dB)
Useable Frequency Range (-10 dB)
42 Hz to 18 kHz
37 Hz to 18 kHz
Maximum Output 2
Calculated Peak Output
Calculated Continuous Output
124 dB SPL
118 dB SPL
Nominal Coverage85° conical DMT™
Nominal Impedance16 ohms
Power Rating
Continuous power handling3
Recommended amplifier power (loudspeaker "program" power)
300 W
600 W
Sensitivity93 dB SPL, 1W/1m
Bass LoadingPorted
Transformer TypeCustom low distortion laminated core, wide bandwidth design
Transformer Taps100 V: 16Ω bypass, 150 W, 75 W, 37.5 W
70 V: 16Ω bypass, 150 W, 75 W, 37.5 W, 18.2 W
Agency RatingCE, UL 1480 (commercial/professional use)
UL 2043 (air handling spaces)

ENCLOSURE

Enclosure VolumeAD-C1200BB: 88 L (3.1 ft 3)
ConnectorsBack box (AD-C1200BB): ceramic block connector inputs and “through” connectors (rated for 400 W max). Loudspeaker Baffle: Euro-style connectors.
Mounting HardwarePre-installed, suspended, back box, four mounting tabs.
Loudspeaker Baffle: six mounting screws.
Weight - NetAD-C1200: 25 lb / 11.3 kg
AD-C1200BB: 53 lb / 24 kg
Complete Assembly: 78 lb / 35.3 kg
Dimensions (HWD)Complete Assembly: 23-inch x 18-inch x 15.5-inch (584 mm x 454 mm x 393 mm)
