ราคาพิเศษ สอบถามโทร 080-6144774 , 02-9810944

รายละเอียดทั้งหมด

BOSCH LBB 1920/00 ปรีแอมป์ สำหรับ โวลท์ไลน์ เครื่องขยาย ระบบประกาศสาธารณะ  Plena PRE Amplifiers  - Four universal low-noise input channels for microphone or line

 - Separate tone control, speech filter and direct output per channel

 - Selectable blocking, serial and mixing priorities

 - Multifunctional inter-connection point

 - Priority and emergency relay outp

Functions

 All input channels provide the choice of a balanced 3‑pin XLR-connector for microphone or line level (selectable), a balanced 5‑pin DIN-connector for microphone or line level with priority contact, or a line level stereo cinch-connector, converted to mono.Microphone inputs have a phantom power supply.Each input channel has its own volume and tone control, a selectable speech filter to reduce the bass content of the speech signal for improved intelligibility, and a balanced, direct output on XLR,that bypasses the channel controls.Three priority modes are available for the input channels. In blocking mode the input channel that is activated first gets priority over all other input channels. In serial mode input channel 1 has priority over channels 2, 3 and 4; channel 2 has priority over channels 3 and 4; and channel 3 has priority over channel 4. Each of the input channels can be mixed to the master output, irrespective of priority, by separately setting that channel to the mixing mode.Balanced XLR interconnection input and output are provided in combination with an insertion/cascade selector. In insertion mode an external sound processing device, e.g. an equalizer, can be connected between these connections. In the cascade mode, multiple LBB1920/00 pre-amplifiers can be cascaded to increase the number of input channels to 8, 12, or even more. Internally the interconnection input can be switched as an emergency input with a signal level detector (VOX). If an emergency audio signal is detected, this channel overrides all others. The emergency input channel has its own volume preset and bypasses the master volume control. For the emergency input another VOX activated relay is provided to trigger external equipment or for local volume control override. An overload protected 24 VDC output provides power for driving external relays,making an external power supply unnecessary.An additional microphone level output is available on the DIN connector, parallel to the balanced XLR master output. This provides an input signal for a mixing desk or a microphone input channel for a mixer amplifier, such as the Plena LBB 19xx/10. A tape output is also available
