BOSE LT-6403

BOSE LT-6403 ลำโพง Panaray Full Range 3-way Loudspeaker ออกแบบสำหรับใช้งานภายในอาคาร มีคุณสมบัติพิเศษควบคุมการกระจายเสียงและเน้นการกระจายเสียงที่ครอบคลุมไป ยังบริเวณที่ต้องการ ด้วยการตอบสนองความถี่ระหว่าง 50 Hz-16 KHz มุมกระจายเสียงแนวนอน 65องศา และแนวตั้ง 52องศา ลำโพง LT6403 จึงเป็นตัวเลือกได้อย่างดีเยี่ยมสำหรับการติดตั้งที่ต้องการเสียงที่มี ประสิทธิภาพอย่างเต็มที่ General Description
The Bose LT 6403 is a full-range 3-way loudspeaker designed as the primary reinforcement source for smaller venues, or for use with other LT loudspeakers to form Coherent Zone arrays in medium to large venues. The large-format waveguide and 60° x 40° pattern deliver precise coverage and high intelligibility, while providing a cost-effective alternative to multiple-cabinet line arrays for many applications

Product Description

Panaray® LT 6403 loudspeaker is a 3-way, high SPL, full range speaker designed for indoor applications. It features dispersion control and focused coverage with a frequency response of 50Hz - 16kHz and a maximum SPL of 121dB (127db peak). The LT 6403 offers a 65° horizontal by 52° vertical dispersion which provides consistent on-and-off axis response. The waveguide can be rotated 90° allowing for easier placement of the speaker. Each loudspeaker also includes a 15-inch woofer. Like Panaray LT mid/high loudspeakers, these full-range models use an innovative Bose® V2 mid-frequency engine. The integrated V2 driver heat sink provides cooler operation and improved reliability. Multiple hang points allow for convenient cluster configuration using industry-standard suspension hardware.
Features
• High degree of pattern control allows designers and installers to effectively control dispersion for clearer, more intelligible sound. • Full-range sound with frequency response down to 50Hz helps reduce the need for a separate bass source. An excellent choice for installations that demand full-range sound but cannot accommodate separate bass components. • A waveguide that can be rotated 90° allowing the loudspeakers to be flown vertically or horizontally while still maintaining the same coverage pattern.

·   Indoor applications only – available in black or white.
