EV,Electro-Voice evid C4.2

 โพสต์เมื่อ : 25 พ.ย 2567 เวลา 0:50 น.
3

3



รหัส : evid C4.2
ยี่ห้อ : EV,Electro-Voice
รุ่น : evid C4.2
ราคาปกติ :  13,000.00 บาท
รายละเอียดย่อ :
4” coaxial 2way speaker with horn loaded Ti coated tweeter-complete with back can enclosure , tile rails , and mounting ring –for 70v/100v or 8 omh

ราคาพิเศษ สอบถามโทร 080-6144774 , 02-9810944

รายละเอียดทั้งหมด

4” coaxial 2way speaker with horn loaded Ti coated tweeter-complete with back can enclosure , tile rails , and mounting ring –for 70v/100v  or  8 omh. Operation.

Tabs at 30, 15, 7.5, 3.75 and 1.88 w.

FEATURES

  • Designed for air-handling spaces
  • Ported enclosure for extended bass response
  • Waveguide-coupled 0.75-inch titanium-coated tweeter
  • Full-bandwidth overload protection
  • Integrated transformer for 70 V, 100 V, or 8 Ω use
  • Front-panel mode/wattage selector
  • Safe, easy installation with included tile bridge and mounting ring
  • White semi-gloss perforated grille
  • Complete package, requires no additional accessories

SPECIFICATION

Chassis Size101.6 mm (4")
ColorWhite (paintable surface)
Coverage (Nominal -6 dB)130 conical
Diameter (Max)181 mm (7.13")
Input Formats8 Ω, 70 V, 100 V
Mounting SystemsIntegrated 3-point toggle anchors
Speaker TypePorted cabinet, internally damped, two-way passive crossover included
TransformerYes
Transformer Taps (Transformer Version Only)(1.88 - 70 V only), 3.75, 7.5, 15, 30
Frequency Response (-10 dB)65 - 20000 Hz
Sensitivity 1 W/1 m86 dB
System Power Handling (Continuous/Program/Peak)80 Watts Overload Protected
LF Transducer4-inch polypropylene cone
HF Transducer0.75-inch (19 mm) Ti Mylar Laminate Dome
Enclosure MaterialSteel enclosure and UL94V-0 rated baffle and bezel
OutdoorNo
GrillPowder-coated steel
Height176 mm (6.93")
Weight Net2.7 kg (5.95 lbs)
