EV,Electro-Voice evid C8.2LP

 โพสต์เมื่อ : 25 พ.ย 2567 เวลา 0:50 น.
6

6



รหัส : evid C8.2LP
ยี่ห้อ : EV,Electro-Voice
รุ่น : evid C8.2LP
ราคาปกติ :  18,200.00 บาท
รายละเอียดย่อ :
8” coaxial 2way speaker with horn loaded Ti coated tweeter-complete with Low-profile back can enclosure , tile rails , and mounting ring –for 70v/100v or 8 omh

ราคาพิเศษ สอบถามโทร 080-6144774 , 02-9810944

รายละเอียดทั้งหมด

8” coaxial 2way speaker with horn loaded Ti coated tweeter-complete with Low-profile back can enclosure , tile rails , and mounting ring –for 70v/100v  or  8 omh. Operation.

Tabs at 30, 15, 7.5, 3.75 and 1.88 w.

FEATURES

  • Low-profile for rich sound in tight spaces
  • Ported enclosure for extended bass response
  • Waveguide-coupled 1-inch titanium-coated tweeter
  • Full-bandwidth overload protection
  • Integrated transformer for 70 V, 100 V, or 8 Ω use
  • Front-panel mode/wattage selector
  • Safe, easy installation with included tile bridge and mounting ring
  • White semi-gloss perforated grille
  • Complete package, requires no additional accessories



SPECIFICATION

Chassis Size203.2 mm (8")
ColorWhite (paintable surface)
Coverage (Nominal -6 dB)110 conical
Diameter (Max)270 mm (10.63")
Input Formats8 Ω, 70 V, 100 V
LP Height255 mm (10.04")
Mounting SystemsIntegrated 3-point toggle anchors
Speaker TypePorted cabinet, internally damped, two-way (passive crossover included)
TransformerYes
Transformer Taps (Transformer Version Only)(1.88 - 70 V only), 3.75, 7.5, 15, 30
Frequency Response (-10 dB)50 - 20000 Hz
Sensitivity 1 W/1 m91 dB
System Power Handling (Continuous/Program/Peak)100 Watts Overload Protected
LF Transducer8-inch polypropylene cone
HF Transducer1-inch (25 mm) Ti Mylar Laminate Dome
Enclosure MaterialSteel enclosure and UL94V-0 rated baffle and bezel
OutdoorNo
GrillPowder-coated steel
Height178 mm (7.01")
Weight Net5 kg (11.02 lbs)
