The T-4S60 4 channel power amplifier has been designed specifically for commercial and industrial public address applications.

itC T-4S60 Four Channel Power Amplifier

With four separate amplifiers in a single unit and a power rating of 60W per channel, the T-4S60 is a powerful and robust solution suitable for many applications.

Both balanced and unbalanced line inputs for each channel make it an ideal choice for most installations while the balanced line outputs for each channel can be fed into an additional amplifier when required. The balanced line out delivers better signal transmission and less noise over longer distances. The 70V, 100V and 4-16 ohm speaker output options for each channel ensure convenient installation no matter the speaker configuration of the system.

The T-4S60 also features master volume controls for each channel as well complete protection from overheating, over loading, clipping & short circuits. Indications for power, signal, clip, protection and temp are also located on the front of the unit for clear and direct monitoring.

Rear Panel

itC T-4S60 Four Channel Power Amplifier Rear Panel

Features

2 separate amplifiers built into a single unit

2U rack mount form factor

60W rated power per channel

70V, 100V and 4-16ohm speaker outputs for each channel

Isolated transformer for safer and more reliable operation

Balanced XLR line inputs and unbalanced 1/4 inch XLR line inputs for each channel

Balanced XLR type line outputs for each channel can be fed to an additional power amplifier

Reliable protection against overheat, overload, clip & short circuit built-in

Front panel indicators for power, signal, clip, protection and temp

Built-in heat sink\cooling fan ensures long and reliable operational life

Specifications

Rated Power Output 4x60W

Speaker Outputs 70V, 100V & 4~16Ω

Input Sensitivity & Impedance ±385mV/10KΩ, Balanced XLR Input

Overload Electromotive Force ?15dB

Frequency Response 50Hz~16KHz (+1dB, -3dB)

S/N Ratio >90dB

THD Less than 0.1% at 1KHz, 1/3 rated power

Crosstalk ?50dB

Cooling Fan automatically start up when temp reaches 55°C

Protection Over heat, over load, clip & short circuit

Power Supply 230V/50Hz or DC 24V

Power Consumption 400W

Dimensions 484x448x88mm

Weight 16 Kg

Finish Black aluminium front panel, black steel chassis

Connection Diagram

itC T-4S60 Four Channel Power Amplifier Connection Diagram
