ITC Audio TI-120S 120W 5-Zone Mixer Amplifier

The Mixer Zone Amplifier series is equiped with priority function.They are designed to suit all PA system application in schools home offices and stores.

Features :

5 zone output and 5 zone separate volume control

Built-in

Built-in 24V interface

Each channel with separate treble and bass control

Built-in 24V phantom power and separate power switch

Capacity of controlling by remote paging MIC

Selectable priority muting.

 Switchable audio signal priority for MIC channels 1.

1 EMC input signal over other input soures, all 100V-open the area.

2 Remote MIC and Telephone input over SIREN, CHIME, MIC 1~4,LINE 1~2, input sources.

3 MIC 1 SIREN CHIME over MIC 2~3, LINE 1~2 input sources.

Specifications :

Amplifier Section(4Ohms Load Output) Rated Output Power (THD 1%) 120W(RMS)

Speaker Zone 1-5 Output 25W 20W Max

Mic Input Section(MIC 1-4 In@1kHz) Input Sensitivity/Impedance 2.45mV/5kOhmBAL/245mV/5kOhmBAL

S/N Better than 55dB

Frequency Response (+-3dB) 100Hz-15kHz

Tone Control (Bass:100Hz, Treble:10kHz) +-12dB

Phantom Power +24VDC

Line Input Section

(Line 1-4 In@1kHz) Input Sensitivity/Impedance 250mV/47kOhm

S/N Better than 65dB

Frequency Response (+-3dB) 80Hz-15kHz

Tone Control (Bass:100Hz, Treble:10kHz) +-12dB

Telaudio Input Input Sensitivity/Impedance 0.3V/10kOhm

S/N Better than 65dB

Frequency Response (+-3dB) 100Hz-15kHz

Preamp Out (MIC 1-4, Line 1-2, Tel In, Remote In) 0dBV/600Ohm

Remote MIC 30mV/600Ohm

T.H.D Less than 0.5%

Power Source ~220-240V; 50/60Hz,24VDC

Power Consumption 200W

Weight 17.1Kg

Dimensions(mm) 484*450*132
