TOA A-5012

 โพสต์เมื่อ : 26 ส.ค 2567 เวลา 15:23 น.
34



35

รหัส : A-5012
ยี่ห้อ : TOA
รุ่น : TOA A-5012
ราคาปกติ :  26,900.00 บาท
ราคาพิเศษ :  22,865.00บาท
ไฟล์เอกสาร : leaflet_en_a-5000+series_2019_final_pages.pdf
รายละเอียดย่อ : TOA A-5012 เครื่องขยายเสียงดิจิตอล 120วัตต์ Digital Mixer Amplifier 120W

ราคาพิเศษ สอบถามโทร 080-6144774 , 02-9810944

รายละเอียดทั้งหมด

TOA A-5012 เครื่องขยายเสียง Digital Mixer Amplifier 120W

The A-5012 is a half-rack 1-unit size 120 W desktop mixer power amplifier. Inputs 1 and 2 can be set for either MIC or LINE sound sources, and its output is compatible with both high-impedance (100 V and 70 V lines) and low-impedance (4 Ω) speaker connections.Functions can be set with a PC using the dedicated setting software. The A-5012 is ideal for use asa power amplifier in small commercial facilities and conference rooms.With the use of an optional rack mounting bracket, it can be mounted in an EIA Standard equipmentrack (1 unit size).



Specification

Power Source100-240 V AC, 50/60 Hz
Rated Output120 W
Power/CurrentConsumption207 W (rated output), 39 W (based on cULus standards)
Max. 3 A
Frequency Response50 Hz - 20 kHz (1/8 rated output)
Distortion1 % or less (1 kHz, rated output)
InputINPUT 1, 2: MIC -60 dB(*1)
LINE -20 dB(*1) MIC/LINE selectable
2.2 kΩ, electronically-balanced, removable terminal block (5 pins)
INPUT 3, 4: LINE -20 dB(*1), 10 kΩ, unbalanced, RCA pin jack
OutputSPEAKER: 4 Ω, 70 V (42 Ω), 100 V (83 Ω), removable terminal block (5 pins)
Signal to Noise RatioMIC 1, 2: 50 dB or more
LINE 1 - 4: 70 dB or more
(A-weighted)
FunctionParametric equalizer: 5 points settable on each input and output
20 Hz - 20 kHz ±15 dB
Q: 0.267 - 69.249
Compressor: ON/OFF settable on Inputs 1 and 2 (OFF by default)
Threshold, Ratio, Attack time, Release time, and Gain are settable
independently on each input.
ControlMute control, Remote master volume control, Power ON/OFF switch, Ground lift
LED IndicatorPower indicator, Signal indicator, Peak indicator, Protect indicator
Network I/F100BASE-TX
Operating Temperature0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
Operating Humidity35 % to 80 %RH (no condensation)
FinishPanel: PS resin, black
Case: Surface-treated steel plate, black, paint
Dimensions210 (W) × 52.5 (H) × 375 (D) mm (8.27 × 2.07" × 14.76")"
Weight3.9 kg (8.6 lb)
AccessoryCD (setting software) …1, Large type removable terminal plug (5 pins) …1, Small type removable terminal plug (5 pins) …2, Plain washer (*2) …6, Bracket mounting screw (M3 x 10) (*2) …6, Power supply cord (2 m (6.56 ft)) …1
OptionHalf width blank panel: MB-15B-BK (for rack mounting one A-5012 unit) (*2)
Rack joint bracket: MB-15B-J (for rack mounting two A-5012 units) (*2)
Rack runner: YA-706

(*1) 0 dB = 1 V
(*2) When using the optional MB-15B-BK or MB-15B-J, use the bracket mounting screws supplied with this unit.
