JBL Ki-112







JBL Ki-112 12 Inch 3-Way Full Range Loudspeaker System

The Ki112 is a 3-way full-range speaker designed specially for KTV market needs. The Ki112 utilizes a single 12” woofer, two 3” cone midrange drivers, and two 3” cone tweeters.12″ woofer with 2.5″ voice coil provides higher power handling

Features :

• 12″ woofer with 2.5″ voice coil provides higher power handling
• Linear suspension and vented yoke design for woofer effectively reduces the distortion and power compression
• Two 3″ cone midrange drivers and two 3″ cone tweeters for better vocal reproduction
• Precision engineered crossover divides accurately and optimizes the three-band frequency response
• Enclosure constructed of MDF (Medium Density Fiberboard) with vinyl laminated finish
• Built-in protection circuit engineered specifically to protect the tweeter without interrupting performance

Specifications :

• System Type : 12″, 3-way, bass-reflex
• Frequency Range (-10 dB) : 45 Hz - 18 KHz
• Frequency Response (±3 dB) : 60 Hz - 16 KHz
• Sensitivity (1w/1m) : 90 dB
• Nominal Impedance : 8 Ohms
• Maximum SPL : 114 dB (120 dB peak) @ 1m
• Power Rating
• (Continuous/Program/Peak) : 250 W/500 W/1000 W
• Recommended amplifier power : 300 W - 400 W @ 8 Ohms
• Coverage Pattern  : 150° x 100° (H x V)
• Dimensions (H x W x D) : 350 mm x 586 mm x 368 mm
• 13.8 in x 23.1 in x 14.5 in
• Net Weight : 17.8 Kg (39.2 lbs)
• LF Driver : 1 x 12″ Woofer
• MF Driver : 2 x 3″ paper cone midrange drivers
• HF Driver : 2 x 3″ paper cone tweeters
• Input Connectors : Binding post
• Enclosure Construction : Vinyl covered 15 mm MDF
• Suspension Attachment : 2 x M10 threaded hardware
